CoolLED Fluorescence Illuminator
The CoolLED pE-300 White multi-channel fluorescence illuminator and control pad.
~25,000 hour life, 10+ years of continuous use. Mercury free. Manual and software control. Direct microscope mount or remote attachment via 3mm liquid light guide.
Broad spectrum, multi-LED fluorescence illumination source. Supports simultaneous or individual Calcein and Alizarin Red fluorescence labeling for dynamic histomorphometry. Label brightness independently adjustable.
Relative Power vs Wavelength
The CoolLED pE-300 White fluorescence illuminator is optimized for three excitation wavelengths, corresponding to blue, red, and green fluorochromes.
Recommended 69401 Multi-band Filter Cube from Chroma
Working with Chroma Technologies, CoolLED has developed a 3 channel filter match to the excitation wavelengths of the CoolLED pE-300 White. Learn more at Chroma.com.
The strength of the three excitation wavelengths (375nm / 475nm / 575nm) are independently controllable. The pE-300 is normally matched to a Chroma 69401 triple-band filter cube. This eliminates the need to switch cubes to view different labels. Labels can be excited individually or simultaneously. Compatible with DAPI, Calceine / FTIC / Alexa 488, Alizarin Red / Texas Red / Alexa 594. Cube sold separately.
Multi-label Imaging Samples
Live dual-label calcein and alizarine red imaging for bone formation rate. Note how well the brightness of the labels are balanced.
Technical Specifications
| Identification | |
|---|---|
| Model Number | pE-300-W-D-SB-201-40 |
| Illumination Wavelength Specifications | |
|---|---|
| First Excitation Wavelength | 375 nm center / 50 nm wide |
| Second Excitation Wavelength | 475 nm center / 50 nm wide |
| Third Excitation Wavelength | 575 nm center / 50 nm wide |
| Intensity Adjustment, Per Channel | 1% to 100% independent adjustment per channel |
| Life Cycle and Safety Specifications | |
|---|---|
| Warm-up Time | Instantaneous |
| LED Illumination Lifetime | ~ 25,000 hours (10+ years continuous use) |
| Manual Illumination Control | Control Pod - On/Off - Intensity Adjust |
| Environmental & Safety | Mercury-Free / Laser-Free |
| Energy Efficiency | ~80% Less Energy than Non-LED Systems |
| Data and Power Specifications | |
|---|---|
| Remote PC Control | USB / Virtual RS232 |
| Power Supply | 100-240VAC, 50.60Hz, 1.4A |
| Power Draw | 2 W / (Standby) 46 W (Maximum Intensity) |
| Physical Specifications | |
|---|---|
| Direct Mount | Interface Varies by Microscope |
| Remote Mount | 3mm Liquid Light Guide |
| Dimensions | 88mm x 125mm x 37mm |
| Mass | 320g |
| Warranty | |
|---|---|
| Warranty Term | 36 Months |
